Black Oxide Precision Shoulder Screws , Standard Hex Head Shoulder Bolt Metric

Name: Black Oxide Precision Shoulder Screws Standard Hex Head Shoulder Bolt Metric
Brand: Runtai
Price: 1 USD

Cheap Black Oxide Precision Shoulder Screws , Standard Hex Head Shoulder Bolt Metric for sale

Brand Name : Runtai

Model Number : Shoulder Screws

Certification : ISO9001/TS16949

Place of Origin : Jiangsu, China (Mainland)

MOQ : 50000

Price : Negotiable

Payment Terms : L/C, T/T, Western Union, MoneyGram, D/A

Supply Ability : 5 Ton/ days

Delivery Time : 15-20 working days

Packaging Details : PP bag+Carton box+ Wooden Pallet

Size : M1-M30 for choose

Material : Steel, Stainless Steel, Brass, Aluminum Alloy

Grade : 4.8 8.8 10.9 12.9 for choose

Surface treatment : zinc plated, nickel plated, black phosphates for choose

Standard : DIN ISO JIS ANSI

Products Name : Black Oxide Alloy Steel Hex Head Shoulder Screws

Contact Now

Black Oxide Alloy Steel Hex Head Shoulder Screws Hex Head Axle Bolts

Products Description

A black oxider alloy steel provides mild corrosion resistance. Also known as wheel and axle bolts, these shoulder screws have a hex head that can be gripped with a wrench. A standard shoulder with an undersized tolerance allows them to fit most machinery and equipment.

Products Specification

Shoulder Fit	Standard
Shoulder Diameter	1/2"
Shoulder Diameter Tolerance	-0.004" to 0"
Shoulder Length	1 5/16"
Shoulder Length Tolerance	-0.005" to 0.005"
Thread Size	3/8"-16
Screw Size Decimal Equivalent	0.375"
Thread Type	UNC
Thread Spacing	Coarse
Thread Fit	Class 2A
Thread Direction	Right Hand
Thread Length	3/4"
Head Width	3/4"
Head Height	1/4"
Material	Steel
Finish	Zinc Plated
Hardness	Rockwell B80
Tensile Strength	70,000 psi
Minimum Shear Strength	35,000 psi
Head Type	Hex
Hex Head Profile	Standard
Head Texture	Smooth
Drive Style	External Hex
System of Measurement	Inch
RoHS	Not Compliant

Note: Material, Size and Surface Treatment for choose.
